ELITE LED UNIVERSAL 12-24V 4 CHANNEL RECEIVER WITH PUSH DIM INPUT

ELITE LED UNIVERSAL 12-24V 4 CHANNEL RECEIVER WITH PUSH DIM INPUT

Regular price £28.00
Regular price Sale price £28.00
Sale Sold out
Shipping calculated at checkout.

A versatile 4 channel receiver unit that is connected to any low voltage, constant voltage lighting products such as LED strip.

To connect to a chosen remote or wall panel – just press the match button on the receiver, and then one press on the chosen controller and that’s it.

* The receiver does all the dimming so a non-dimmable power supply is required. *

  • Operating Voltage: 12-36VDC
  • Max Output Current: 4CH, 5A/CH
  • Output Power: 4 x (60-180W) (720W Total)
  • Dimensions: 175 x 45 x 27mm
  • Input Signal: RF 2.4GHz + Push Dim
  • Dimming Range: 0-100%
  • Remote Distance: 30 metres

Being so universal means, it can either be used for RGB, RGBW, Dual Colour (CCT) or a single colour controller

You can choose from a handheld remote – wall mounted touch panel switch.
